AM20kW electrolyzer test bench can be used for testing 20kW AEM electrolyzer cell. This station can control the flow, pressure and temperature of the anode and cathode of the electrolyzer and simulate the working condition, and collect various data of it.
*Customized products, please send your requirements to info@tensortechs.com
● Anode (cathode) KOH solution flow and pressure control
● Gas production rate and concentration measurement
● Stack temperature control
● Water supply conductivity & level control
● Exhaust water recovery and amount/content test
● Pressure regulation at high pressure during flow rate shift
● Electrolyzer work condition simulation and performance test
● Cell Voltage Monitoring
● Intrinsic safety & alarming system
● HMI with Data Acquisition & Analysis
● 24/7 Unattended Operation
● HFR
● Pressure Boost
● H2 Mix
● Water Balance
● Dual Coolant
● Gas Analyze
● High Accuracy Power Supply
| Min P/kW | Max P/kW | H2/NLPM | O2/NLPM | Coolant/LPM | Current/A | Stack Temp/°C | Gas Pressure /Barg | Cell# | Cell Hardware | EIS | HFR | Pressure Boost | H2 Mix | Water Balance | Gas Analyze | Dual Coolant | DI Polish | High Accr. Power Supply | |
| 1 | 20 | 80 | 40 | 25 | 1500 | 90 | 50 | 48 | O | O | O | O | O | O | Y | O |
