AEM electrolyser Test Benches simulate work condition of AEM electrolyser stack and conduct perfomance test, durability test and electrochemistry analysis of AEM cells/stacks.
| DUT | Model | Min P/kW | Max P/kW | H2/NLPM | O2/NLPM | Coolant/LPM | Current/A | Stack Temp/°C | Gas Pressure /Barg | Cell# | Cell Hardware | EIS | HFR | Pressure Boost | H2 Mix | Water Balance | Gas Analyze | Dual Coolant | DI Polish | High Accr. Power Supply | |
| AEM Electrolyser Tester | AM300W | 0.015 | 0.3 | 1 | 0.5 | 0.4 | 150 | 90 | 50 | 4 | O | O | O | O | O | O | O | Y | O | ||
| AEM Electrolyser Tester | AM500W | 0.025 | 0.5 | 2 | 1 | 0.75 | 150 | 90 | 50 | 8 | O | O | O | O | O | O | O | Y | O | ||
| AEM Electrolyser Tester | AM1 | 0.05 | 1 | 5 | 2.5 | 1 | 250 | 90 | 50 | 12 | O | O | O | O | O | O | O | Y | O | ||
| AEM Electrolyser Tester | AM10 | 0.5 | 10 | 50 | 25 | 12 | 500 | 90 | 50 | 24 | O | O | O | O | O | O | Y | O | |||
| AEM Electrolyser Tester | AM20 | 1 | 20 | 80 | 40 | 25 | 1500 | 90 | 50 | 48 | O | O | O | O | O | O | Y | O | |||
| AEM Electrolyser Tester | AM50 | 2.5 | 50 | 180 | 90 | 50 | 6000 | 90 | 50 | 72 | O | O | O | O | O | O | Y | O |
Anode solution flow and pressure control with dry/wet mode
Optional Cathode solution flow and pressure control with dry/wet mode
Gas production rate and concentration measurement
Stack temperature control
Water supply conductivity& level control
Optional Solution PH level control
Exhaust water separation and amount/content sampling
Pressure regulation at high pressure during flow rate shift
Electrolyser work condition simulation and performance test
Cell Voltage Monitoring
Intrinsic safety& alarming system
HMI with data acquisition& analysis
24/7 Unattained Operation
Pressure boost with nitrogen
The liquid recirculation modules on Anode (and optional Cathode) supplies KOH or other solutions to the DUT (Device-Under-Testing) at demanded temperature and flow rates. After the electrlysis process while reaction pressure and temperature are controlled, H2/O2 mix with liquid and then exit the DUT and then go to the separation module to remove water. After the drying process, the gases enter analyzing modules to measure flow rates and concentrations.
1. Cathode gas back pressure control technology: Install a new type of back pressure valve on the cathode gas discharge path of the electrolytic cell to improve the accuracy of back pressure control.
2. Large-span flow rate regulation technology. The test bench is downward compatible and can meet the testing requirements of some unconventional working conditions.
3. Precise control technology for alkali solution concentration. Continuously adjust the supply of pure water or alkali solution based on the real-time alkali solution concentration collected by the alkali solution concentration meter to ensure that the alkali solution concentration remains within a controllable range.
